Heavy-Duty Guard Rail 18" High Corner Post
Delivery and Shipping
Delivery and Shipping
Shipping calculated at checkout. All truck and parcel shipments are packaged for safe and efficient delivery of materials; learn more.
Heavy-Duty Guard Rail 18" High Corner Post
RP-SCOYW is an 18" corner post for our single-rail-high Steel Guard lineup of heavy-duty guard rail safety products. The post is 4" square with a 1/4" thick steel wall and a 10" square base, USA-made, and powder coated for durability in a highly visible and UV resistant yellow color. Posts also include four 3/4" x 5-1/2" anchors, a cap, and rail mounting hardware for installation. Compatible with Steel Guard rails, additional post styles, and accessories (sold separately) – you can easily create and install a leading barrier to protect your employees, guests, racking, machinery, and facility.
Steel Guard premium, pre-fabricated, modular guard rail systems are easy to configure and install to create the perfect guard for the areas you want to protect. One fork lift accident prevented or machine saved from damage will quickly provide a positive return on the investment into the industry's leading guard rail solution. After more than 40,000 installations, no other brand exceeds the rugged design of Steel Guard – tested and proven at 13,440 lbs. impact force (unit tested: 42" tall unit with two levels of three ribbed rails; learn more).
-
Series
-
Size Summary
-
Rail Levels
-
Connection Type
-
Width (in.)
-
Depth (in.)
-
Height (in.)
-
Finish Method
-
Color
-
Material
-
Construction
-
Compliance
Need help designing or specifying the right components? We can help! Chat or contact us now. If you are tackling yourself, feel free to use this helpful guide:
- Choose the height of your system. Steel Guard is available in either single (18" high posts) or double high (43" high posts).
- Choose your necessary post type. Standard corner posts are available. Center posts are available in four options: standard, standard offset, end offset, and side offset.
- Choose your rail lengths. Note that rails are measured from post-to-post, on center; the actual rail component will be 4″ shorter than the specified length on Steel Guard. Lift-out pockets increase the center-to-center dimension by 1″.
- Choose bolted or lift-out rail. The lift-out rail provides equipment protection while still enabling easy access when needed.
- Are gates needed? Steel Guard gate includes all hardware and end caps for easy installation without cutting, welding, or drilling. It can be flipped for in-swing or out-swing orientation.
